Module Task_CARGO
Tasking (Release 2.1) -- The TASK_CARGO models tasks for players to transport Cargo.
Cargo are units or cargo objects within DCS world that allow to be transported or sling loaded by other units. The CARGO class, as part of the moose core, is able to Board, Load, UnBoard and UnLoad from Carrier units. This collection of classes in this module define tasks for human players to handle cargo objects. Cargo can be transported, picked-up, deployed and sling-loaded from and to other places.
The following classes are important to consider:
- #TASKCARGOTRANSPORT: Defines a task for a human player to transport a set of cargo between various zones.
==
API CHANGE HISTORY
The underlying change log documents the API changes. Please read this carefully. The following notation is used:
- Added parts are expressed in bold type face.
- Removed parts are expressed in italic type face.
Hereby the change log:
2017-03-09: Revised version.
AUTHORS and CONTRIBUTIONS
Contributions:
Authors:
- FlightControl: Concept, Design & Programming.
Global(s)
| TASK_CARGO |
TASK_CARGO class, extends Task#TASKThe TASK_CARGO class defines Cargo transport tasks, based on the tasking capabilities defined in Task#TASK. |
| TASK_CARGO_TRANSPORT |
Type FSM_PROCESS
| FSM_PROCESS.Cargo | |
| FSM_PROCESS.DeployZone |
Type TASK_CARGO
| TASK_CARGO:AddDeployZone(DeployZone, TaskUnit) | |
| TASK_CARGO.DeployZones | |
| TASK_CARGO:GetPlannedMenuText() | |
| TASK_CARGO:GetTargetZone(TaskUnit) | |
| TASK_CARGO:New(Mission, SetGroup, TaskName, SetCargo, TaskType) |
Instantiates a new TASK_CARGO. |
| TASK_CARGO:RemoveDeployZone(DeployZone, TaskUnit) | |
| TASK_CARGO.SetCargo | |
| TASK_CARGO:SetCargoPickup(Cargo, TaskUnit) | |
| TASK_CARGO:SetDeployZone(DeployZone, TaskUnit) | |
| TASK_CARGO:SetDeployZones(@, TaskUnit, DeployZones) | |
| TASK_CARGO:SetPenaltyOnFailed(Text, Penalty, TaskUnit) |
Set a penalty when the A2G attack has failed. |
| TASK_CARGO:SetScoreOnDestroy(Text, Score, TaskUnit) |
Set a score when a target in scope of the A2G attack, has been destroyed . |
| TASK_CARGO:SetScoreOnSuccess(Text, Score, TaskUnit) |
Set a score when all the targets in scope of the A2G attack, have been destroyed. |
| TASK_CARGO.TaskType |
Type TASK_CARGO_TRANSPORT
| TASK_CARGO_TRANSPORT.ClassName | |
| TASK_CARGO_TRANSPORT:New(Mission, SetGroup, TaskName, SetCargo) |
Instantiates a new TASKCARGOTRANSPORT. |
Global(s)
- #TASK_CARGO TASK_CARGO
-
TASK_CARGO class, extends Task#TASK
The TASK_CARGO class defines Cargo transport tasks, based on the tasking capabilities defined in Task#TASK.
The TASK_CARGO is implemented using a Statemachine#FSM_TASK, and has the following statuses:
- None: Start of the process.
- Planned: The cargo task is planned.
- Assigned: The cargo task is assigned to a Group#GROUP.
- Success: The cargo task is successfully completed.
- Failed: The cargo task has failed. This will happen if the player exists the task early, without communicating a possible cancellation to HQ.
1.1) Set the scoring of achievements in a cargo task.
Scoring or penalties can be given in the following circumstances:
Type Task_CARGO
Type FSM_PROCESS
Field(s)
Type TASK_CARGO
Field(s)
- TASK_CARGO:AddDeployZone(DeployZone, TaskUnit)
-
Parameters
-
Core.Zone#ZONE DeployZone: -
Wrapper.Unit#UNIT TaskUnit:
Return value
-
- TASK_CARGO.DeployZones
-
setmetatable( {}, { __mode = "v" } ) -- weak table on value
- TASK_CARGO:GetTargetZone(TaskUnit)
-
Parameter
-
Wrapper.Unit#UNIT TaskUnit:
Return value
Core.Zone#ZONE_BASE: The Zone object where the Target is located on the map.
-
- TASK_CARGO:New(Mission, SetGroup, TaskName, SetCargo, TaskType)
-
Instantiates a new TASK_CARGO.
Parameters
-
Tasking.Mission#MISSION Mission: -
Set#SET_GROUP SetGroup: The set of groups for which the Task can be assigned. -
#string TaskName: The name of the Task. -
Core.Set#SET_CARGO SetCargo: The scope of the cargo to be transported. -
#string TaskType: The type of Cargo task.
Return value
#TASK_CARGO: self
-
- TASK_CARGO:RemoveDeployZone(DeployZone, TaskUnit)
-
Parameters
-
Core.Zone#ZONE DeployZone: -
Wrapper.Unit#UNIT TaskUnit:
Return value
-
- TASK_CARGO:SetCargoPickup(Cargo, TaskUnit)
-
Parameters
-
AI.AICargo#AICARGO Cargo: The cargo. -
Wrapper.Unit#UNIT TaskUnit:
Return value
-
- TASK_CARGO:SetDeployZone(DeployZone, TaskUnit)
-
Parameters
-
Core.Zone#ZONE DeployZone: -
Wrapper.Unit#UNIT TaskUnit:
Return value
-
- TASK_CARGO:SetDeployZones(@, TaskUnit, DeployZones)
-
Parameters
-
@: ist -
Wrapper.Unit#UNIT TaskUnit: -
DeployZones:
Return value
-
- TASK_CARGO:SetPenaltyOnFailed(Text, Penalty, TaskUnit)
-
Set a penalty when the A2G attack has failed.
Parameters
-
#string Text: The text to display to the player, when the A2G attack has failed. -
#number Penalty: The penalty in points. -
Wrapper.Unit#UNIT TaskUnit:
Return value
-
- TASK_CARGO:SetScoreOnDestroy(Text, Score, TaskUnit)
-
Set a score when a target in scope of the A2G attack, has been destroyed .
Parameters
-
#string Text: The text to display to the player, when the target has been destroyed. -
#number Score: The score in points. -
Wrapper.Unit#UNIT TaskUnit:
Return value
-
- TASK_CARGO:SetScoreOnSuccess(Text, Score, TaskUnit)
-
Set a score when all the targets in scope of the A2G attack, have been destroyed.
Parameters
-
#string Text: The text to display to the player, when all targets hav been destroyed. -
#number Score: The score in points. -
Wrapper.Unit#UNIT TaskUnit:
Return value
-
Type TASK_CARGO_TRANSPORT
The TASKCARGOTRANSPORT class
Field(s)
- #string TASK_CARGO_TRANSPORT.ClassName
- TASK_CARGO_TRANSPORT:New(Mission, SetGroup, TaskName, SetCargo)
-
Instantiates a new TASKCARGOTRANSPORT.
Parameters
-
Tasking.Mission#MISSION Mission: -
Set#SET_GROUP SetGroup: The set of groups for which the Task can be assigned. -
#string TaskName: The name of the Task. -
Core.Set#SET_CARGO SetCargo: The scope of the cargo to be transported.
Return value
#TASKCARGOTRANSPORT: self
-
