Module AI_Formation

AI -- (R2.1) Build large formations of AI Groups flying together.

Banner Image

AI_FORMATION makes AI GROUPs fly in formation of various compositions. The AI_FORMATION class models formations in a different manner than the internal DCS formation logic!!! The purpose of the class is to:

  • Make formation building a process that can be managed while in flight, rather than a task.
  • Human players can guide formations, consisting of larget planes.
  • Build large formations (like a large bomber field).
  • Form formations that DCS does not support off the shelve.

A few remarks:

  • Depending on the type of plane, the change in direction by the leader may result in the formation getting disentangled while in flight and needs to be rebuild.
  • Formations are vulnerable to collissions, but is depending on the type of plane, the distance between the planes and the speed and angle executed by the leader.
  • Formations may take a while to build up.

As a result, the AI_FORMATION is not perfect, but is very useful to:

  • Model large formations when flying straight line.
  • Make humans guide a large formation, when the planes are wide from each other.

There are the following types of classes defined:

Demo Missions

AI_FORMATION Demo Missions source code

AI_FORMATION Demo Missions, only for beta testers

ALL Demo Missions pack of the last release

YouTube Channel

AUTHORS and CONTRIBUTIONS

Contributions:

Authors:

  • FlightControl: Concept, Design & Programming.

Global(s)

AI_FORMATION

AI_FORMATION class, extends Fsm#FSM_SET

The #AI_FORMATION class allows you to build large formations, make AI follow a Client#CLIENT (player) leader or a Unit#UNIT (AI) leader.

Type AI_FORMATION

AI_FORMATION.FlightRandomization
AI_FORMATION.FollowDistance

The current follow distance.
AI_FORMATION.FollowGroupSet
AI_FORMATION.FollowMenuResumeMission
AI_FORMATION.FollowMode

The mode the escort is in.
AI_FORMATION.FollowName
AI_FORMATION.FollowScheduler

The instance of the SCHEDULER class.
AI_FORMATION.FollowUnit
AI_FORMATION:FormationBox(XStart, XSpace, YStart, YSpace, ZStart, ZSpace, ZLevels)

FormationBox Trigger for AI_FORMATION
AI_FORMATION:FormationCenterWing(XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationCenterWing Trigger for AI_FORMATION
AI_FORMATION:FormationLeftLine(XStart, YStart, ZStart, ZSpace)

FormationLeftLine Trigger for AI_FORMATION
AI_FORMATION:FormationLeftWing(XStart, XSpace, YStart, ZStart, ZSpace)

FormationLeftWing Trigger for AI_FORMATION
AI_FORMATION:FormationLine(XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationLine Trigger for AI_FORMATION
AI_FORMATION:FormationRightLine(XStart, YStart, ZStart, ZSpace)

FormationRightLine Trigger for AI_FORMATION
AI_FORMATION:FormationRightWing(XStart, XSpace, YStart, ZStart, ZSpace)

FormationRightWing Trigger for AI_FORMATION
AI_FORMATION:FormationStack(XStart, XSpace, YStart, YSpace)

FormationStack Trigger for AI_FORMATION
AI_FORMATION:FormationTrail(XStart, XSpace, YStart)

FormationTrail Trigger for AI_FORMATION
AI_FORMATION:FormationVic(XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationVic Trigger for AI_FORMATION
AI_FORMATION:New(FollowUnit, FollowGroupSet, FollowName, FollowBriefing)

AI_FORMATION class constructor for an AI group
AI_FORMATION:OnAfterFormationBox(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace, ZLevels)

FormationBox Handler OnAfter for AI_FORMATION
AI_FORMATION:OnAfterFormationCenterWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationCenterWing Handler OnAfter for AI_FORMATION
AI_FORMATION:OnAfterFormationLeftLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationLeftLine Handler OnAfter for AI_FORMATION
AI_FORMATION:OnAfterFormationLeftWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)

FormationLeftWing Handler OnAfter for AI_FORMATION
AI_FORMATION:OnAfterFormationLine(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationLine Handler OnAfter for AI_FORMATION
AI_FORMATION:OnAfterFormationRightLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationRightLine Handler OnAfter for AI_FORMATION
AI_FORMATION:OnAfterFormationRightWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)

FormationRightWing Handler OnAfter for AI_FORMATION
AI_FORMATION:OnAfterFormationStack(From, Event, To, XStart, XSpace, YStart, YSpace)

FormationStack Handler OnAfter for AI_FORMATION
AI_FORMATION:OnAfterFormationTrail(From, Event, To, XStart, XSpace, YStart)

FormationTrail Handler OnAfter for AI_FORMATION
AI_FORMATION:OnAfterFormationVic(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationVic Handler OnAfter for AI_FORMATION
AI_FORMATION:OnBeforeFormationBox(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace, ZLevels)

FormationBox Handler OnBefore for AI_FORMATION
AI_FORMATION:OnBeforeFormationCenterWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationCenterWing Handler OnBefore for AI_FORMATION
AI_FORMATION:OnBeforeFormationLeftLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationLeftLine Handler OnBefore for AI_FORMATION
AI_FORMATION:OnBeforeFormationLeftWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)

FormationLeftWing Handler OnBefore for AI_FORMATION
AI_FORMATION:OnBeforeFormationLine(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationLine Handler OnBefore for AI_FORMATION
AI_FORMATION:OnBeforeFormationRightLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationRightLine Handler OnBefore for AI_FORMATION
AI_FORMATION:OnBeforeFormationRightWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)

FormationRightWing Handler OnBefore for AI_FORMATION
AI_FORMATION:OnBeforeFormationStack(From, Event, To, XStart, XSpace, YStart, YSpace)

FormationStack Handler OnBefore for AI_FORMATION
AI_FORMATION:OnBeforeFormationTrail(From, Event, To, XStart, XSpace, YStart)

FormationTrail Handler OnBefore for AI_FORMATION
AI_FORMATION:OnBeforeFormationVic(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationVic Handler OnBefore for AI_FORMATION
AI_FORMATION.OptionReactionOnThreat

Which REACTIONONTHREAT is set to the FollowGroup.
AI_FORMATION.ReportTargets

If true, nearby targets are reported.
AI_FORMATION:SetFlightRandomization(FlightRandomization)

Use the method AIFormation#AIFORMATION.SetFlightRandomization() to make the air units in your formation randomize their flight a bit while in formation.
AI_FORMATION.SmokeDirectionVector
AI_FORMATION:TestSmokeDirectionVector(SmokeDirection)

This function is for test, it will put on the frequency of the FollowScheduler a red smoke at the direction vector calculated for the escort to fly to.
AI_FORMATION:__FormationBox(Delay, XStart, XSpace, YStart, YSpace, ZStart, ZSpace, ZLevels)

FormationBox Asynchronous Trigger for AI_FORMATION
AI_FORMATION:__FormationCenterWing(Delay, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationCenterWing Asynchronous Trigger for AI_FORMATION
AI_FORMATION:__FormationLeftLine(Delay, XStart, YStart, ZStart, ZSpace)

FormationLeftLine Asynchronous Trigger for AI_FORMATION
AI_FORMATION:__FormationLeftWing(Delay, XStart, XSpace, YStart, ZStart, ZSpace)

FormationLeftWing Asynchronous Trigger for AI_FORMATION
AI_FORMATION:__FormationLine(Delay, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationLine Asynchronous Trigger for AI_FORMATION
AI_FORMATION:__FormationRightLine(Delay, XStart, YStart, ZStart, ZSpace)

FormationRightLine Asynchronous Trigger for AI_FORMATION
AI_FORMATION:__FormationRightWing(Delay, XStart, XSpace, YStart, ZStart, ZSpace)

FormationRightWing Asynchronous Trigger for AI_FORMATION
AI_FORMATION:__FormationStack(Delay, XStart, XSpace, YStart, YSpace)

FormationStack Asynchronous Trigger for AI_FORMATION
AI_FORMATION:__FormationTrail(Delay, XStart, XSpace, YStart)

FormationTrail Asynchronous Trigger for AI_FORMATION
AI_FORMATION:__FormationVic(Delay, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationVic Asynchronous Trigger for AI_FORMATION
AI_FORMATION:onafterFormationBox(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace, ZLevels, FollowGroupSet)

FormationBox Handler OnAfter for AI_FORMATION
AI_FORMATION:onafterFormationCenterWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationCenterWing Handler OnAfter for AI_FORMATION
AI_FORMATION:onafterFormationLeftLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationLeftLine Handler OnAfter for AI_FORMATION
AI_FORMATION:onafterFormationLeftWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)

FormationLeftWing Handler OnAfter for AI_FORMATION
AI_FORMATION:onafterFormationLine(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationLine Handler OnAfter for AI_FORMATION
AI_FORMATION:onafterFormationRightLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationRightLine Handler OnAfter for AI_FORMATION
AI_FORMATION:onafterFormationRightWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)
AI_FORMATION:onafterFormationStack(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace)

FormationStack Handler OnAfter for AI_FORMATION
AI_FORMATION:onafterFormationTrail(FollowGroupSet, From, Event, To, XStart, XSpace, YStart)

FormationTrail Handler OnAfter for AI_FORMATION
AI_FORMATION:onafterFormationVic(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace, FollowGroupSet)

FormationVic Handle for AI_FORMATION
AI_FORMATION:onenterFollowing(FollowGroupSet)

Type AI_FORMATION.MODE

AI_FORMATION.MODE.FOLLOW
AI_FORMATION.MODE.MISSION

Type MENUPARAM

MENUPARAM.ParamDistance
MENUPARAM.ParamFunction
MENUPARAM.ParamMessage
MENUPARAM.ParamSelf

Global(s)

#AI_FORMATION AI_FORMATION

AI_FORMATION class, extends Fsm#FSM_SET

The #AI_FORMATION class allows you to build large formations, make AI follow a Client#CLIENT (player) leader or a Unit#UNIT (AI) leader.

AI_FORMATION makes AI GROUPs fly in formation of various compositions. The AI_FORMATION class models formations in a different manner than the internal DCS formation logic!!! The purpose of the class is to:

  • Make formation building a process that can be managed while in flight, rather than a task.
  • Human players can guide formations, consisting of larget planes.
  • Build large formations (like a large bomber field).
  • Form formations that DCS does not support off the shelve.

A few remarks:

  • Depending on the type of plane, the change in direction by the leader may result in the formation getting disentangled while in flight and needs to be rebuild.
  • Formations are vulnerable to collissions, but is depending on the type of plane, the distance between the planes and the speed and angle executed by the leader.
  • Formations may take a while to build up.

As a result, the AI_FORMATION is not perfect, but is very useful to:

  • Model large formations when flying straight line. You can build close formations when doing this.
  • Make humans guide a large formation, when the planes are wide from each other.

AI_FORMATION construction

Create a new SPAWN object with the AI_FORMATION.New method:

Formation methods

The following methods can be used to set or change the formation:

Randomization

Use the method AIFormation#AIFORMATION.SetFlightRandomization() to simulate the formation flying errors that pilots make while in formation. Is a range set in meters.

Usage:

local FollowGroupSet = SET_GROUP:New():FilterCategories("plane"):FilterCoalitions("blue"):FilterPrefixes("Follow"):FilterStart()
FollowGroupSet:Flush()
local LeaderUnit = UNIT:FindByName( "Leader" )
local LargeFormation = AI_FORMATION:New( LeaderUnit, FollowGroupSet, "Center Wing Formation", "Briefing" )
LargeFormation:FormationCenterWing( 500, 50, 0, 250, 250 )
LargeFormation:__Start( 1 )

Type AI_Formation

Type AI_FORMATION

AI_FORMATION class

Field(s)

AI_FORMATION.FlightRandomization
#number AI_FORMATION.FollowDistance

The current follow distance.

Set#SET_GROUP AI_FORMATION.FollowGroupSet
Menu#MENU_CLIENT AI_FORMATION.FollowMenuResumeMission
#AI_FORMATION.MODE AI_FORMATION.FollowMode

The mode the escort is in.

#string AI_FORMATION.FollowName
Scheduler#SCHEDULER AI_FORMATION.FollowScheduler

The instance of the SCHEDULER class.

Unit#UNIT AI_FORMATION.FollowUnit
AI_FORMATION:FormationBox(XStart, XSpace, YStart, YSpace, ZStart, ZSpace, ZLevels)

FormationBox Trigger for AI_FORMATION

Parameters

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

  • #number ZLevels : The amount of levels on the Z-axis.

AI_FORMATION:FormationCenterWing(XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationCenterWing Trigger for AI_FORMATION

Parameters

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:FormationLeftLine(XStart, YStart, ZStart, ZSpace)

FormationLeftLine Trigger for AI_FORMATION

Parameters

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:FormationLeftWing(XStart, XSpace, YStart, ZStart, ZSpace)

FormationLeftWing Trigger for AI_FORMATION

Parameters

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:FormationLine(XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationLine Trigger for AI_FORMATION

Parameters

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:FormationRightLine(XStart, YStart, ZStart, ZSpace)

FormationRightLine Trigger for AI_FORMATION

Parameters

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:FormationRightWing(XStart, XSpace, YStart, ZStart, ZSpace)

FormationRightWing Trigger for AI_FORMATION

Parameters

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:FormationStack(XStart, XSpace, YStart, YSpace)

FormationStack Trigger for AI_FORMATION

Parameters

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

AI_FORMATION:FormationTrail(XStart, XSpace, YStart)

FormationTrail Trigger for AI_FORMATION

Parameters

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

AI_FORMATION:FormationVic(XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationVic Trigger for AI_FORMATION

Parameters

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:New(FollowUnit, FollowGroupSet, FollowName, FollowBriefing)

AI_FORMATION class constructor for an AI group

Parameters

  • Unit#UNIT FollowUnit : The UNIT leading the FolllowGroupSet.

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string FollowName : Name of the escort.

  • FollowBriefing :

Return value

#AI_FORMATION: self

AI_FORMATION:OnAfterFormationBox(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace, ZLevels)

FormationBox Handler OnAfter for AI_FORMATION

Parameters

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

  • #number ZLevels : The amount of levels on the Z-axis.

AI_FORMATION:OnAfterFormationCenterWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationCenterWing Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:OnAfterFormationLeftLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationLeftLine Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:OnAfterFormationLeftWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)

FormationLeftWing Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:OnAfterFormationLine(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationLine Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:OnAfterFormationRightLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationRightLine Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:OnAfterFormationRightWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)

FormationRightWing Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:OnAfterFormationStack(From, Event, To, XStart, XSpace, YStart, YSpace)

FormationStack Handler OnAfter for AI_FORMATION

Parameters

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

AI_FORMATION:OnAfterFormationTrail(From, Event, To, XStart, XSpace, YStart)

FormationTrail Handler OnAfter for AI_FORMATION

Parameters

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

AI_FORMATION:OnAfterFormationVic(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationVic Handler OnAfter for AI_FORMATION

Parameters

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:OnBeforeFormationBox(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace, ZLevels)

FormationBox Handler OnBefore for AI_FORMATION

Parameters

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

  • #number ZLevels : The amount of levels on the Z-axis.

Return value

#boolean:

AI_FORMATION:OnBeforeFormationCenterWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationCenterWing Handler OnBefore for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

Return value

#boolean:

AI_FORMATION:OnBeforeFormationLeftLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationLeftLine Handler OnBefore for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

Return value

#boolean:

AI_FORMATION:OnBeforeFormationLeftWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)

FormationLeftWing Handler OnBefore for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

Return value

#boolean:

AI_FORMATION:OnBeforeFormationLine(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationLine Handler OnBefore for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

Return value

#boolean:

AI_FORMATION:OnBeforeFormationRightLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationRightLine Handler OnBefore for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

Return value

#boolean:

AI_FORMATION:OnBeforeFormationRightWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)

FormationRightWing Handler OnBefore for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

Return value

#boolean:

AI_FORMATION:OnBeforeFormationStack(From, Event, To, XStart, XSpace, YStart, YSpace)

FormationStack Handler OnBefore for AI_FORMATION

Parameters

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

Return value

#boolean:

AI_FORMATION:OnBeforeFormationTrail(From, Event, To, XStart, XSpace, YStart)

FormationTrail Handler OnBefore for AI_FORMATION

Parameters

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

Return value

#boolean:

AI_FORMATION:OnBeforeFormationVic(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationVic Handler OnBefore for AI_FORMATION

Parameters

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

Return value

#boolean:

DCSTypes#AI.Option.Air.val.REACTION_ON_THREAT AI_FORMATION.OptionReactionOnThreat

Which REACTIONONTHREAT is set to the FollowGroup.

#boolean AI_FORMATION.ReportTargets

If true, nearby targets are reported.

AI_FORMATION:SetFlightRandomization(FlightRandomization)

Use the method AIFormation#AIFORMATION.SetFlightRandomization() to make the air units in your formation randomize their flight a bit while in formation.

Parameter

  • #number FlightRandomization : The formation flying errors that pilots can make while in formation. Is a range set in meters.

Return value

#AI_FORMATION:

AI_FORMATION.SmokeDirectionVector
AI_FORMATION:TestSmokeDirectionVector(SmokeDirection)

This function is for test, it will put on the frequency of the FollowScheduler a red smoke at the direction vector calculated for the escort to fly to.

This allows to visualize where the escort is flying to.

Parameter

  • #boolean SmokeDirection : If true, then the direction vector will be smoked.

Return value

#AI_FORMATION:

AI_FORMATION:__FormationBox(Delay, XStart, XSpace, YStart, YSpace, ZStart, ZSpace, ZLevels)

FormationBox Asynchronous Trigger for AI_FORMATION

Parameters

  • #number Delay :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

  • #number ZLevels : The amount of levels on the Z-axis.

AI_FORMATION:__FormationCenterWing(Delay, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationCenterWing Asynchronous Trigger for AI_FORMATION

Parameters

  • #number Delay :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:__FormationLeftLine(Delay, XStart, YStart, ZStart, ZSpace)

FormationLeftLine Asynchronous Trigger for AI_FORMATION

Parameters

  • #number Delay :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:__FormationLeftWing(Delay, XStart, XSpace, YStart, ZStart, ZSpace)

FormationLeftWing Asynchronous Trigger for AI_FORMATION

Parameters

  • #number Delay :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:__FormationLine(Delay, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationLine Asynchronous Trigger for AI_FORMATION

Parameters

  • #number Delay :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:__FormationRightLine(Delay, XStart, YStart, ZStart, ZSpace)

FormationRightLine Asynchronous Trigger for AI_FORMATION

Parameters

  • #number Delay :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:__FormationRightWing(Delay, XStart, XSpace, YStart, ZStart, ZSpace)

FormationRightWing Asynchronous Trigger for AI_FORMATION

Parameters

  • #number Delay :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:__FormationStack(Delay, XStart, XSpace, YStart, YSpace)

FormationStack Asynchronous Trigger for AI_FORMATION

Parameters

  • #number Delay :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

AI_FORMATION:__FormationTrail(Delay, XStart, XSpace, YStart)

FormationTrail Asynchronous Trigger for AI_FORMATION

Parameters

  • #number Delay :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

AI_FORMATION:__FormationVic(Delay, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationVic Asynchronous Trigger for AI_FORMATION

Parameters

  • #number Delay :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:onafterFormationBox(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace, ZLevels, FollowGroupSet)

FormationBox Handler OnAfter for AI_FORMATION

Parameters

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

  • #number ZLevels : The amount of levels on the Z-axis.

  • FollowGroupSet :

Return value

#AI_FORMATION:

AI_FORMATION:onafterFormationCenterWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationCenterWing Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:onafterFormationLeftLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationLeftLine Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

Return value

#AI_FORMATION:

AI_FORMATION:onafterFormationLeftWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)

FormationLeftWing Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

AI_FORMATION:onafterFormationLine(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace)

FormationLine Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

Return value

#AI_FORMATION:

AI_FORMATION:onafterFormationRightLine(FollowGroupSet, From, Event, To, XStart, YStart, ZStart, ZSpace)

FormationRightLine Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

Return value

#AI_FORMATION:

AI_FORMATION:onafterFormationRightWing(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, ZStart, ZSpace)

Parameters

  • FollowGroupSet :

  • From :

  • Event :

  • To :

  • XStart :

  • XSpace :

  • YStart :

  • ZStart :

  • ZSpace :

AI_FORMATION:onafterFormationStack(FollowGroupSet, From, Event, To, XStart, XSpace, YStart, YSpace)

FormationStack Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

Return value

#AI_FORMATION:

AI_FORMATION:onafterFormationTrail(FollowGroupSet, From, Event, To, XStart, XSpace, YStart)

FormationTrail Handler OnAfter for AI_FORMATION

Parameters

  • Core.Set#SET_GROUP FollowGroupSet : The group AI escorting the FollowUnit.

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

Return value

#AI_FORMATION:

AI_FORMATION:onafterFormationVic(From, Event, To, XStart, XSpace, YStart, YSpace, ZStart, ZSpace, FollowGroupSet)

FormationVic Handle for AI_FORMATION

Parameters

  • #string From :

  • #string Event :

  • #string To :

  • #number XStart : The start position on the X-axis in meters for the first group.

  • #number XSpace : The space between groups on the X-axis in meters for each sequent group.

  • #nubmer YStart : The start position on the Y-axis in meters for the first group.

  • #number YSpace : The space between groups on the Y-axis in meters for each sequent group.

  • #nubmer ZStart : The start position on the Z-axis in meters for the first group.

  • #number ZSpace : The space between groups on the Z-axis in meters for each sequent group.

  • FollowGroupSet :

Return value

#AI_FORMATION:

AI_FORMATION:onenterFollowing(FollowGroupSet)

Parameter

  • FollowGroupSet :

Type AI_FORMATION.MODE

AI_FORMATION.Mode class

Field(s)

#number AI_FORMATION.MODE.FOLLOW
#number AI_FORMATION.MODE.MISSION

Type Distance

Type MENUPARAM

MENUPARAM type

Field(s)

#Distance MENUPARAM.ParamDistance
#function MENUPARAM.ParamFunction
#string MENUPARAM.ParamMessage
#AI_FORMATION MENUPARAM.ParamSelf

Type nubmer
