Module Functional.Mantis
Functional -- Modular, Automatic and Network capable Targeting and Interception System for Air Defenses
MANTIS - Moose derived Modular, Automatic and Network capable Targeting and Interception System Controls a network of SAM sites.
Use detection to switch on the AA site closest to the enemy Leverage evasiveness from SEAD Leverage attack range setup added by DCS in 11/20
Missions:
MANTIS - Modular, Automatic and Network capable Targeting and Interception System
Author : *applevangelist *
Global(s)
Global MANTIS |
The worst thing that can happen to a good cause is, not to be skillfully attacked, but to be ineptly defended. - Frédéric Bastiat Simple Class for a more intelligent Air Defense System MANTISMoose derived Modular, Automatic and Network capable Targeting and Interception System. |
The worst thing that can happen to a good cause is, not to be skillfully attacked, but to be ineptly defended. - Frédéric Bastiat
Simple Class for a more intelligent Air Defense System
MANTIS
Moose derived Modular, Automatic and Network capable Targeting and Interception System.
Controls a network of SAM sites. Use detection to switch on the AA site closest to the enemy. Leverage evasiveness from Functional.Sead#SEAD. Leverage attack range setup added by DCS in 11/20.
Set up your SAM sites in the mission editor. Name the groups with common prefix like "Red SAM". Set up your EWR system in the mission editor. Name the groups with common prefix like "Red EWR". Can be e.g. AWACS or a combination of AWACS and Search Radars like e.g. EWR 1L13 etc. [optional] Set up your HQ. Can be any group, e.g. a command vehicle.
1. Basic tactical considerations when setting up your SAM sites
1.1 Radar systems and AWACS
Typically, your setup should consist of EWR (early warning) radars to detect and track targets, accompanied by AWACS if your scenario forsees that. Ensure that your EWR radars have a good coverage of the area you want to track. Location is of highest importantance here. Whilst AWACS in DCS has almost the "all seeing eye", EWR don't have that. Choose your location wisely, against a mountain backdrop or inside a valley even the best EWR system doesn't work well. Prefer higher-up locations with a good view; use F7 in-game to check where you actually placed your EWR and have a look around. Apart from the obvious choice, do also consider other radar units for this role, most have "SR" (search radar) or "STR" (search and track radar) in their names, use the encyclopedia to see what they actually do.
1.2 SAM sites
Typically your SAM should cover all attack ranges. The closer the enemy gets, the more systems you will need to deploy to defend your location. Use a combination of long-range systems like the SA-10/11, midrange like SA-6 and short-range like SA-2 for defense (Patriot, Hawk, Gepard, Blindfire for the blue side). For close-up defense and defense against HARMs or low-flying aircraft, helicopters it is also advisable to deploy SA-15 TOR systems, Shilka, Strela and Tunguska units, as well as manpads (Think Gepard, Avenger, Chaparral, Linebacker, Roland systems for the blue side). If possible, overlap ranges for mutual coverage.
1.3 Typical problems
Often times, people complain because the detection cannot "see" oncoming targets and/or Mantis switches on too late. Three typial problems here are
- bad placement of radar units,
- overestimation how far units can "see" and
- not taking into account that a SAM site will take (e.g for a SA-6) 30-40 seconds between switching to RED, acquiring the target and firing.
An attacker doing 350knots will cover ca 180meters/second or thus more than 6km until the SA-6 fires. Use triggers zones and the ruler in the missione editor to understand distances and zones. Take into account that the ranges given by the circles in the mission editor are absolute maximum ranges; in-game this is rather 50-75% of that depending on the system. Fiddle with placement and options to see what works best for your scenario, and remember everything in here is in meters.
2. Start up your MANTIS with a basic setting
myredmantis = MANTIS:New("myredmantis","Red SAM","Red EWR",nil,"red",false)
myredmantis:Start()
[optional] Use
- MANTIS:SetEWRGrouping(radius)
- MANTIS:SetEWRRange(radius)
- MANTIS:SetSAMRadius(radius)
- MANTIS:SetDetectInterval(interval)
- MANTIS:SetAutoRelocate(hq, ewr)
before starting #MANTIS to fine-tune your setup.
If you want to use a separate AWACS unit (default detection range: 250km) to support your EWR system, use e.g. the following setup:
mybluemantis = MANTIS:New("bluemantis","Blue SAM","Blue EWR",nil,"blue",false,"Blue Awacs")
mybluemantis:Start()
3. Default settings
By default, the following settings are active:
- SAM_Templates_Prefix = "Red SAM" - SAM site group names in the mission editor begin with "Red SAM"
- EWR_Templates_Prefix = "Red EWR" - EWR group names in the mission editor begin with "Red EWR" - can also be combined with an AWACS unit
- checkradius = 25000 (meters) - SAMs will engage enemy flights, if they are within a 25km around each SAM site -
MANTIS:SetSAMRadius(radius) - grouping = 5000 (meters) - Detection (EWR) will group enemy flights to areas of 5km for tracking -
MANTIS:SetEWRGrouping(radius) - acceptrange = 80000 (meters) - Detection (EWR) will on consider flights inside a 80km radius -
MANTIS:SetEWRRange(radius) - detectinterval = 30 (seconds) - MANTIS will decide every 30 seconds which SAM to activate -
MANTIS:SetDetectInterval(interval) - engagerange = 85 (percent) - SAMs will only fire if flights are inside of a 85% radius of their max firerange -
MANTIS:SetSAMRange(range) - dynamic = false - Group filtering is set to once, i.e. newly added groups will not be part of the setup by default -
MANTIS:New(name,samprefix,ewrprefix,hq,coaltion,dynamic) - autorelocate = false - HQ and (mobile) EWR system will not relocate in random intervals between 30mins and 1 hour -
MANTIS:SetAutoRelocate(hq, ewr) - debug = false - Debugging reports on screen are set to off -
MANTIS:Debug(onoff)
4. Advanced Mode
Advanced mode will decrease reactivity of MANTIS, if HQ and/or EWR network dies. Awacs is counted as one EWR unit. It will set SAMs to RED state if both are dead. Requires usage of an HQ object and the dynamic option.
E.g. mymantis:SetAdvancedMode( true, 90 )
Use this option if you want to make use of or allow advanced SEAD tactics.
5. Integrate SHORAD
You can also choose to integrate Mantis with Functional.Shorad#SHORAD for protection against HARMs and AGMs. When SHORAD detects a missile fired at one of MANTIS' SAM sites, it will activate SHORAD systems in the given defense checkradius around that SAM site. Create a SHORAD object first, then integrate with MANTIS like so:
local SamSet = SET_GROUP:New():FilterPrefixes("Blue SAM"):FilterCoalitions("blue"):FilterStart()
myshorad = SHORAD:New("BlueShorad", "Blue SHORAD", SamSet, 22000, 600, "blue")
-- now set up MANTIS
mymantis = MANTIS:New("BlueMantis","Blue SAM","Blue EWR",nil,"blue",false,"Blue Awacs")
mymantis:AddShorad(myshorad,720)
mymantis:Start()
and (optionally) remove the link later on with
mymantis:RemoveShorad()
6. Integrated SEAD
MANTIS is using Functional.Sead#SEAD internally to both detect and evade HARM attacks. No extra efforts needed to set this up! Once a HARM attack is detected, MANTIS (via SEAD) will shut down the radars of the attacked SAM site and take evasive action by moving the SAM vehicles around (if they are drivable, that is). There's a component of randomness in detection and evasion, which is based on the skill set of the SAM set (the higher the skill, the more likely). When a missile is fired from far away, the SAM will stay active for a period of time to stay defensive, before it takes evasive actions.
You can link into the SEAD driven events of MANTIS like so:
function mymantis:OnAfterSeadSuppressionPlanned(From, Event, To, Group, Name, SuppressionStartTime, SuppressionEndTime)
-- your code here - SAM site shutdown and evasion planned, but not yet executed
-- Time entries relate to timer.getTime() - see https://wiki.hoggitworld.com/view/DCS_func_getTime
end
function mymantis:OnAfterSeadSuppressionStart(From, Event, To, Group, Name)
-- your code here - SAM site is emissions off and possibly moving
end
function mymantis:OnAfterSeadSuppressionEnd(From, Event, To, Group, Name)
-- your code here - SAM site is back online
end
Type(s)
| Fields and Methods inherited from MANTIS | Description |
|---|---|
|
The #DETECTION_AREAS object for AWACS |
|
|
Function to link up #MANTIS with a #SHORAD installation |
|
|
The EWR #SET_GROUP used for advanced mode |
|
|
[Internal] Function to check if any object is in the given SAM zone |
|
|
Function to set switch-on/off the debug state |
|
|
The #DETECTION_AREAS object for EWR |
|
|
The EWR #SET_GROUP |
|
|
Prefix to build the #SET_GROUP for EWR group |
|
|
Function to get the HQ object for further use |
|
|
The #GROUP object of the HQ |
|
|
The ME name of the HQ object |
|
MANTIS:New(name, samprefix, ewrprefix, hq, coaltion, dynamic, awacs, EmOnOff, Padding) |
Function to instantiate a new object of class MANTIS |
MANTIS:OnAfterAdvStateChange(From, Event, To, Oldstate, Newstate, Interval) |
On After "AdvStateChange" event. |
|
On After "GreenState" event. |
|
|
On After "RedState" event. |
|
|
On After "Relocating" event. |
|
MANTIS:OnAfterSeadSuppressionEnd(From, Event, To, Group, Name) |
On After "SeadSuppressionEnd" event. |
|
On After "SeadSuppressionPlanned" event. |
|
MANTIS:OnAfterSeadSuppressionStart(From, Event, To, Group, Name) |
On After "SeadSuppressionStart" event. |
MANTIS:OnAfterShoradActivated(From, Event, To, Name, Radius, Ontime) |
On After "ShoradActivated" event. |
|
Function to unlink #MANTIS from a #SHORAD installation |
|
|
The SAM #SET_GROUP |
|
|
Table of SAM sites |
|
|
Prefix to build the #SET_GROUP for SAM sites |
|
|
Function to set Advanded Mode |
|
|
Function to set autorelocation for HQ and EWR objects. |
|
|
Function to set separate AWACS detection instance |
|
|
Function to set AWACS detection range. |
|
|
Function to set the HQ object for further use |
|
|
Function to set the detection interval |
|
|
Function to set the grouping radius of the detection in meters |
|
|
Function to set the detection radius of the EWR in meters |
|
|
Function to set a new SAM firing engage range, use this method to adjust range while running MANTIS, e.g. |
|
|
Function to set switch-on/off zone for the SAM sites in meters |
|
|
Function to set SAM firing engage range, 0-100 percent, e.g. |
|
|
[Internal] Function to set the SAM start state |
|
|
Set using an #INTEL_DLINK object instead of #DETECTION |
|
|
Set using Emissions on/off instead of changing alarm state |
|
|
SHORAD Object, if available |
|
|
Distance of an attacker in meters from a Mantis SAM site, on which Shorad will be switched on. Useful to not give away Shorad sites too early. Default 15km. Should be smaller than checkradius. |
|
|
If true, #MANTIS has #SHORAD enabled |
|
|
Timer in seconds, how long #SHORAD will be active after a detection inside of the defense range |
|
|
Triggers the FSM event "Start". |
|
|
[Internal] Function to start the detection via AWACS if defined as separate |
|
|
[Internal] Function to start the detection via EWR groups |
|
|
Triggers the FSM event "Status". |
|
|
Decide if we are using Emissions on/off (true) or AlarmState red/green (default) |
|
|
[Internal] Function to determine state of the advanced mode |
|
|
[Internal] Check detection function |
|
|
[Internal] Check advanced state |
|
|
[Internal] Check DLink state |
|
|
[Internal] Function to check if EWR is (at least partially) alive |
|
|
[Internal] Function to check if HQ is alive |
|
|
[Internal] Function to get the self.SAM_Table |
|
|
[Internal] Function to update SAM table and SEAD state |
|
|
[Internal] Relocation relay function |
|
|
[Internal] Function to execute the relocation |
|
|
[Internal] Function to set the self.SAM_Table |
|
|
Triggers the FSM event "Start" after a delay. |
|
|
Triggers the FSM event "Status" after a delay. |
|
|
Triggers the FSM event "Stop" after a delay. |
|
|
Radius of the EWR detection |
|
|
Boolean switch to use Awacs as a separate detection stream |
|
|
Percentage to use for advanced mode, defaults to 100% |
|
|
Advanced mode state tracker |
|
|
Use advanced mode, will decrease reactivity of MANTIS, if HQ and/or EWR network dies. Set SAMs to RED state if both are dead. Requires usage of an HQ object |
|
|
Relocate HQ and EWR groups in random intervals. Note: You need to select units for this which are actually mobile |
|
|
Detection range of an optional Awacs unit |
|
|
Radius of the SAM sites |
|
|
Switch on extra messages |
|
|
Interval in seconds for the target detection |
|
|
Firing engage range of the SAMs, see [https://wiki.hoggitworld.com/view/DCS_option_engagementRange] |
|
|
Radius to group detected objects |
|
|
Prefix for logging |
|
|
Name of this Mantis |
|
MANTIS:onafterAdvStateChange(From, Event, To, Oldstate, Newstate, Interval) |
[Internal] Function triggered by Event AdvStateChange |
|
[Internal] Function triggered by Event GreenState |
|
|
[Internal] Function triggered by Event RedState |
|
|
[Internal] Function triggered by Event Relocating |
|
MANTIS:onafterSeadSuppressionEnd(From, Event, To, Group, Name) |
[Internal] Function triggered by Event SeadSuppressionEnd |
|
[Internal] Function triggered by Event SeadSuppressionPlanned |
|
MANTIS:onafterSeadSuppressionStart(From, Event, To, Group, Name) |
[Internal] Function triggered by Event SeadSuppressionStart |
MANTIS:onafterShoradActivated(From, Event, To, Name, Radius, Ontime) |
[Internal] Function triggered by Event ShoradActivated |
|
[Internal] Function to set start state |
|
|
[Internal] Status function for MANTIS |
|
|
[Internal] Function to stop MANTIS |
|
|
[Internal] Before status function for MANTIS |
|
|
Switch on extra logging |
|
